BPCB012 Series

BPCB012 ultrathin pancake series slip ring, thickess can up to 5.8 mm, adopt PCB substrate，which made of super hard gold plating, super thick copper foil process, maximum current can up to 10A,color-coded lead wires are used on both the stator and rotor for simplified electrical conenctors.
