BXME2122 Series

BXME2122,support 2 channels 1000M ethernet slip rings, with through bore size 12.7mm(0.5"), overall diaBXMEter 56mm, are standard, off-the-shelf, Color-coded lead wires are used on both the stator and rotor for simplified electrical connections.
